"Direct" Fuel Flow Meter (up to 500 litres/hour) with Normalised Outputs and Built-in Display

SKU: -DIRECT
Direct Fuel flow meter
up to 500 litres/hour
Normalised Pulse output + Display and Additional Interface Options
10-50v Power Supply
  • Sensor
  • Flow Range
  • Remote Display
  • $404.83
  • $485.79 inc VAT
Qty:

Description

  • SKU
    -DIRECT

Direct Fuel flow meter

up to 500 litres/hour
Normalised Pulse output + Display and Additional Interface Options
10-50v Power Supply

Direct Fuel flow meters are constructed from hard aluminium alloy, and the measuring chamber has an antifriction coating.
A fuel temperature sensor is installed in the measuring chamber.
Each flow meter manufactured is pre-calibrated.

  • High-precision measurement
  • High corrosion resistance
  • Strong electronic circuit protection
  • Sealed automobile connector on sensor body
  • Indication lights means the user can easily see the state of the device


Specification


    Direct Fuel flow meter

    up to 500 litres/hour
    Normalised Pulse output + Display and Additional Interface Options
    10-50v Power Supply
    • Connecting thread M14 x 1.5
    • Maximum pressure 2.5MPa
    • Accuracy ±1%
    • Temperature range -40°C to 85°C
    • Reverse polarity protection
    • IP67 protection
