Digital Gas Flow Meter:: DN50, 0.65 - 65 Nm3/hr, 2" BSP Connections

SKU: MF50GD65
Digital Gas Flow Meter:: DN50, 0.65 - 65 Nm3/hr
Thermal Mass Flow Measurement,
Digital Display

Pulse and RS485 outputs available

  • PULSE OUTPUT
  • RS485
  • FLANGES
  • £751.12
  • £901.34 inc VAT
Qty:

Description

  • Weight
    4.9000 kg
  • SKU
    MF50GD65

Digital Gas Flow Meter:: DN32, 0.65 - 65 Nm3/hr

Thermal Mass Flow Measurement,
Digital Display

Pulse and RS485 outputs available

Features ::

Range 0.65 - 65 Nm3/hr
Starting Rate 0.1Nm3/h
Li-Ion Battery ( Can be Replaced) 3 yr life
Max Pressure 2 Bar , Temperature Range -10 to +55 deg C
Accuracy +/- 1.5% ( Within Stated Flow Range) Cal cert supplied
Aluminium Construction
LCD Display Flowrate ,Accumulated Flowrate,Battery Status
IP66 Ingress Protection
RS 485 (Modbus) , Pulse Output
Automatic Temperature and Pressure Compensation






Specification


    Features ::

    Range 0.65 - 65 Nm3/hr
    Starting Rate 0.1 Nm3/h
    Li-Ion Battery ( Can be Replaced) 3yr life
    Max Pressure 2 Bar ,
    Temperature Range -10 to +55 deg C
    Accuracy +/- 1.5% ( Within Stated Flow Range) Supplied with calibration certificate
    Aluminium Construction
    LCD Display shows Flowrate , Accumulated total, and Battery Status
    IP66 Ingress Protection
    RS 485 (Modbus) & Pulse Output options
    Automatic Temperature and Pressure Compensation



Downloads
