Low Flow Gas Meter:: DN12 , 3 - 300 SLPM

Low Flow Gas Meter:: DN12 , 3 - 300 SLPM

SKU: MF5012
Low Flow Gas Meter:: DN12 , 3 - 300 SLPM
Thermal Mass Flow Measurement,
Digital Display
  • Connection
  • Proof
  • Min Flow Rate
  • Max Flow Rate
  • Pressure
  • Output
  • Gas
  • £880.00
  • £1056.00 inc VAT


Description


Low Flow Gas Meter::

DN12 , 3 - 300 SLPM
Thermal Mass Flow Measurement, Digital Display
Application:: Process Gas Control ,Environmental Samplers etc.
Extremely Low Pressure Loss




Specification


    Features :

    • Range 3 - 300 SLPM
    • Highly Sensitive.
    • Measure as low as 8mm/sec to 65m/sec
    • Power Supply , 8 - 24 Vdc
    • Max Pressure 3.0MPa ,
    • Temperature Range -20 to +60 deg C
    • Accuracy +/- 1.5 % ( Within Stated Flow Range)
    • Outputs,4-20mA ; RS485; Pulse ( or Combination thereof)
    • Modbus Protocol for easy Networking and Remote Control
    • Available with Display ( Flowrate and Accumulated Flow) or Without
    • Calibration on N2 @20 deg C,101.325kPa
    • Available with / without Ex Proof
    • Automatic Temperature and Pressure Compensation
