MRM - Metreg Rotary Gas Flow Meter :: DN50, G16

MRM - Metreg Rotary Gas Flow Meter :: DN50, G16
Nominal Size: DN50
Meter Size: G16
Pressure Class: PN16
Measuring range: 50:1, 0.5 - 25m3/h
MID Class 1 (2004/22/EG), OIML R137-1 & 2: 2012, Ex-Zone 1
Meter housing: Aluminium
Pistons: Aluminium
Synchronisation Wheels: Stainless Steel
Both bearing sides in oil bath
Index head: Composite, 8-digit, 355 degree Rotation
Sensor Included: 1xLF (Reed) Typ 10 Imp/m3

The MRM rotary displacement gas meter is a high precision custody transfer grade instrument for gas volume measurement and flow measurement of natural gas and other non-aggressive gases in gas stations and plants. The MRM rotary gas meter is applicable in residential and office buildings as well as commercial and industrial plants.

The MRM rotary gas meter registers the operating volume using an eight-digit mechanical counter. Via pulses the operating volume can be transferred to an electronic volume corrector (EVC) and converted to normal or standard conditions. The MRM rotary meter is approved for custody transfer according to MID (2004/22/EC) / OIML.

 Key features

• Meter sizes G 10 to G 1000
• Flow rates from 0.5 to 1600 m3/h
• Nominal sizes from DN 25 to DN 200
• Pressure class PN 10/16 and ANSI Class 150
• Measuring range standard 1:50 (G 25 1:40), optional up to 1:200
• Meter housing made of anodized high strength Aluminum
• Index head by default made of synthetic material, optional made of Aluminum
• Rotating counter (355 °)
• No flow conditioning or straight lengths of pipe required
• Horizontal and vertical mounting position
• Approvals according to MID (2004/22/EC), OIML, PED (PED 97/23/EC), ATEX
