PFM6 Portable hydraulic tester :: 3/4" BSP, 7.5-113.6 L/min, P,T & Q

SKU: F5111CE-BAR

PFM6 Portable hydraulic tester
Simultaneously Measures Flow, Pressure and Temperature
3/4" BSP, 7.5-113.6 L/min
Anodized Aluminium
Battery Digital Display
Max 414 Bar
CE Certified

  • £2868.05
  • £3441.66 inc VAT
Qty:

Description

  • SKU
    F5111CE-BAR

PFM6 Portable hydraulic tester
Simultaneously Measures Flow, Pressure and Temperature
3/4" BSP, 7.5-113.6 L/min
Battery Digital Display
Anodized Aluminium
Max 414 Bar
CE Certified

Features:

• Models cover Five flow ranges
• Large 3-1/2" digit LCD showing flow and temperature
• Helical Bourdon tube pressure gauge
• Turbine flow sensor provides fast response
• Hydraulic Loading valve with fingertip control of system pressure
• One toggle switch to control power and also select flow and temperature
• Available with BSPP ports (or SAE connections)
• PT Platinum resistance temperature sensor
• Safety Bursting Disc fitted (replaceable) for pressure surge protection
• Pressures up to 414 Bar (6000 psi)
• Temperatures up to 150 °C
• Flow accuracy: ±1% of full scale flow
• Repeatability: ±0.2%




Specification
