PFM6BD Portable hydraulic tester (Bi-Directional Model)
Simultaneously Measures Flow, Pressure and Temperature
1" BSP, 15 - 321 L/min
Battery Digital Display
Anodized Aluminium
Max 414 Bar
CE Certified
Features:
• Models cover Five flow ranges
• Large 3-1/2" digit LCD showing flow and temperature
• Helical Bourdon tube pressure gauge
• Turbine flow sensor provides fast response
• Hydraulic Loading valve with fingertip control of system pressure
• One toggle switch to control power and also select flow and temperature
• Available with BSPP ports (or SAE connections)
• PT Platinum resistance temperature sensor
• Safety Bursting Disc fitted (replaceable) for pressure surge protection
• Pressures up to 414 Bar (6000 psi)
• Temperatures up to 150 °C
• Flow Accuracy: Forward ±1% of full scale , Reverse ±2% of full scale
• Repeatability: ±0.2%
