VuHeat add DN15 model to range of Ultrasonic Heat meters

Jul 17, 2024

DN15 model added to existing VuHeat Heat energy flow meter range. MID Class 2 Ultrasonic technology

Our range of Thermal Heat energy flow meters for heating and cooling measurement requirement in small and large pipes, provide cost-efficient and compliant solutions for Domestic heat meter requirements. Our comprehensive range of MID Class 2 heat meters are suitable for use on biomass boilers, Solar thermal and heat pump systems etc. Sizes range from 15mm through to 300mm and above are approved for use on typically domestic applications.

Product Features

» Metrological measurement to EN1434 standard
» MID Approved
» MID Class 2 Approved 1/2" Qp 1.5 m3/hr (0.6 m3/h optional)
» Superior Ultrasonic Measurement principle
» Low energy consumption ~ 10 year battery life
» Display may be dismounted for easier viewing
» Measurement range between 5 – 90 °C
» 16 Bar Max working Pressure
» 1/2” BSP PN16 screwed connections
» M-Bus communications protocol (see options)
