Qbic Lite 1 or 2 Channel Data Logger, Web Portal Access and Built-in Solar Charger

SKU: Qbic Lite

Qbic Lite 1 or 2 Channel Data Logger
Various Input options: Pulse, 4-20mA, SDI12 etc
Remote Access Via Secure Web Portal
Android / IOS App available
IP67 Rated Ingress Protection
Over-heating protection
Integrated Solar Charger and Rechargeable Battery

  • Inputs
  • £455.00
  • £546.00 inc VAT
Qty:

Description

  • Weight
    0.4000 kg
  • SKU
    Qbic Lite



Qbic Lite 1 or 2 Channel Data Logger
Various Input options: Pulse, 4-20mA, SDI12 etc
Remote Access Via Secure Web Portal
Android / IOS App available
IP67 Rated Ingress Protection
Over-heating protection
Integrated Solar Charger and Rechargeable Battery



Wireless communications based on the M2M network over GSM-GPRS and 3G. Global coverage (communications work in any country in the world *
This low-cost solutions offers you your own free cloud portal access with no monthly charges !

Specification

    Qbic Lite 1 or 2 Channel Data Logger
    Various Input options: Pulse, 4-20mA, SDI12 etc
    Remote Access Via Secure Web Portal
    Android / IOS App available
    IP67 Rated Ingress Protection
    Over-heating protection
    Integrated Solar Charger and Rechargeable Battery



    Application Example: Qbic lite monitors the water that reaches the crop by connecting a soil moisture sensor and a water meter, or monitors solar radiation and ambient temperature / humidity to calculate evapotranspiration … with Qbic Lite you still have all the power of a professional datalogger but with a smaller number of inputs and outputs to adjust itself in price and adapt to very specific needs.





    Inputs

    1 connector

     Maximum number of sensors connected at the same time: 1

    Up to 1 analog inputs.

    Up to 1 pulse input for connection with flow meters, pluviometer, anemometer and others.

    Up to 1 SDI12 sensor: Sentek Drill and Drop, Decagon: 5TE, GS3, 5TE and many others.

    Input for ambient temperature / humidity sensor.



    2 connector

     Maximum number of sensors connected at the same time: 2

    Up to 2 analog inputs.

    Up to 2 pulse input for connection with flow meters, pluviometer, anemometer and others.

    Up to 2 SDI12 sensor: Sentek Drill and Drop, Decagon: 5TE, GS3, 5TE and many others.

    Input for ambient temperature / humidity sensor.



    Outputs



    Qbic Agricultural dataloggers enable you to control other devices via their control outputs (available on request). Through their voltage outputs they can also supply active sensors that require power or even small hydraulic pumps.

    Voltage outputs: (in the Qbic 1C you would have to choose between one or the other):

    • 3 VDC
    • 5 VDC

    Internal characteristics



    Internal temperature sensor

    Overheating protection system

    Lithium Polymer Battery

    Recharging battery via solar panel integrated in the device

    Monitoring the battery status

    Accessories for easy installation on any diameter pole



    Wireless Communications



    Wireless communications based on the M2M network over GSM-GPRS and 3G.

    Global coverage (communications work in any country in the world *)

    Multi-operator. It automatically uses the Cellular network with the best coverage.



    Weight and
    Dimensions



    130 x 95 x 65 mm

    Approximate weight: 400 g
